Ceiling steel profile specifications.Interior Utility Angles
The Hopestar Building Hopestar®range of Interior Utility angles are manufactured from 50ksi steel with a minimum of G40 galvanized coating.Utility angle is used in a variety of applications including corner reinforcement and soffit construction.
Standard length is 10’
Available with leg heights of 1-1/2”,2”,2-1/2”,3”and 4”
Custom lengths and sizes are available
Can I substitute specified products for Hopestar products?
Absolutely,our insistence on quality and extensive product testing provide substantial evidence that our products provide equal performance characteristics of alternative framing systems.Further information can be found on our Hopestars Conformance document.
Why choose Hopestar?
As an innovative and industry leading company,Hopestar provides quality products,solution-based engineering,and hands-on customer service.There are many reasons to choose Hopestar products for your project,here are some of the many benefits.
Where are Hopestar products manufactured and what materials are used for?
Hopestar products are manufactured in Hopestar,Hopestar.Our products are made from premium quality Steel.They are manufactured within the strictest of tolerances and are structurally sound when installed in accordance with our Design Manual.
Product Code Product Information Width(mm)Design thickness Coating Mils Lb/ft
UA-11218 Interior Utility Angles 1-1/2"0.0188 G40 18 Mils 0.21
UA-11230 Interior Utility Angles 1-1/2"0.0312 G40 30 Mils 0.32
UA-11218-G60 Interior Utility Angles 1-1/2"0.0188 G60 18 Mils 0.21
UA-11230-G60 Interior Utility Angles 1-1/2"0.0312 G60 30 Mils 0.32
UA-1230 Interior Utility Angles 1"0.0312 G40 30 Mils 0.32
UA-1230-G60 Interior Utility Angles 1"0.0312 G60 30 Mils 0.32
UA-218 Interior Utility Angles 2"0.0188 G40 18 Mils 0.27
UA-230 Interior Utility Angles 2"0.0312 G40 30 Mils 0.41
UA-218-G60 Interior Utility Angles 2"0.0188 G60 18 Mils 0.27
UA-230-G60 Interior Utility Angles 2"0.0312 G60 30 Mils 0.41
UA-21218 Interior Utility Angles 2-1/2"0.0188 G40 18 Mils 0.34
UA-21230 Interior Utility Angles 2-1/2"0.0312 G40 30 Mils 0.51
UA-21218-G60 Interior Utility Angles 2-1/2"0.0188 G60 18 Mils 0.34
UA-21230-G60 Interior Utility Angles 2-1/2"0.0312 G60 30 Mils 0.51
UA-318 Interior Utility Angles 3"0.0188 G40 18 Mils 0.41
UA-330 Interior Utility Angles 3"0.0312 G40 30 Mils 0.63
UA-318-G60 Interior Utility Angles 3"0.0188 G60 18 Mils 0.41
UA-330-G60 Interior Utility Angles 3"0.0312 G60 30 Mils 0.63
UA-430 Interior Utility Angles 4"0.0312 G40 30 Mils 0.78
UA-430-G60 Interior Utility Angles 4"0.0312 G60 30 Mils 0.78
Let’s grow together.We have advanced production equipment,leading production techniques,and strictly quality control.And We manufacture products from high-quality steel coils,products,and sales service make as your one-stop decoration construction supply shop.Hopestar Building is the senior steel manufacturer,the factory has more than 50 sets of production lines for galvanized steel profiles,T grid,and Accessories.The annual product quantity is 20,000 Tons.The factory has developed business with South America,Europe,Africa,and Oceania.we supply and have a commitment to making customers’projects a reality.
The Hopestar Building Hopestar®range of Interior Utility angles are manufactured from 50ksi steel with a minimum of G40 galvanized coating.Utility angle is used in a variety of applications including corner reinforcement and soffit construction.
Standard length is 10’
Available with leg heights of 1-1/2”,2”,2-1/2”,3”and 4”
Custom lengths and sizes are available
Can I substitute specified products for Hopestar products?
Absolutely,our insistence on quality and extensive product testing provide substantial evidence that our products provide equal performance characteristics of alternative framing systems.Further information can be found on our Hopestars Conformance document.
Why choose Hopestar?
As an innovative and industry leading company,Hopestar provides quality products,solution-based engineering,and hands-on customer service.There are many reasons to choose Hopestar products for your project,here are some of the many benefits.
Where are Hopestar products manufactured and what materials are used for?
Hopestar products are manufactured in Hopestar,Hopestar.Our products are made from premium quality Steel.They are manufactured within the strictest of tolerances and are structurally sound when installed in accordance with our Design Manual.
Product Code Product Information Width(mm)Design thickness Coating Mils Lb/ft
UA-11218 Interior Utility Angles 1-1/2"0.0188 G40 18 Mils 0.21
UA-11230 Interior Utility Angles 1-1/2"0.0312 G40 30 Mils 0.32
UA-11218-G60 Interior Utility Angles 1-1/2"0.0188 G60 18 Mils 0.21
UA-11230-G60 Interior Utility Angles 1-1/2"0.0312 G60 30 Mils 0.32
UA-1230 Interior Utility Angles 1"0.0312 G40 30 Mils 0.32
UA-1230-G60 Interior Utility Angles 1"0.0312 G60 30 Mils 0.32
UA-218 Interior Utility Angles 2"0.0188 G40 18 Mils 0.27
UA-230 Interior Utility Angles 2"0.0312 G40 30 Mils 0.41
UA-218-G60 Interior Utility Angles 2"0.0188 G60 18 Mils 0.27
UA-230-G60 Interior Utility Angles 2"0.0312 G60 30 Mils 0.41
UA-21218 Interior Utility Angles 2-1/2"0.0188 G40 18 Mils 0.34
UA-21230 Interior Utility Angles 2-1/2"0.0312 G40 30 Mils 0.51
UA-21218-G60 Interior Utility Angles 2-1/2"0.0188 G60 18 Mils 0.34
UA-21230-G60 Interior Utility Angles 2-1/2"0.0312 G60 30 Mils 0.51
UA-318 Interior Utility Angles 3"0.0188 G40 18 Mils 0.41
UA-330 Interior Utility Angles 3"0.0312 G40 30 Mils 0.63
UA-318-G60 Interior Utility Angles 3"0.0188 G60 18 Mils 0.41
UA-330-G60 Interior Utility Angles 3"0.0312 G60 30 Mils 0.63
UA-430 Interior Utility Angles 4"0.0312 G40 30 Mils 0.78
UA-430-G60 Interior Utility Angles 4"0.0312 G60 30 Mils 0.78
Let’s grow together.We have advanced production equipment,leading production techniques,and strictly quality control.And We manufacture products from high-quality steel coils,products,and sales service make as your one-stop decoration construction supply shop.Hopestar Building is the senior steel manufacturer,the factory has more than 50 sets of production lines for galvanized steel profiles,T grid,and Accessories.The annual product quantity is 20,000 Tons.The factory has developed business with South America,Europe,Africa,and Oceania.we supply and have a commitment to making customers’projects a reality.
